AMD Ryzen 7 7800X3D 8-Core, 16-Thread Desktop Processor

AMD Ryzen 7 7800X3D

General Specifications

Regional Availability

Global

Platform

Desktop

Product Family

AMD Ryzen Processors

Product Line

AMD Ryzen 7 Processors

 of CPU Cores

8

 of Threads

16

Max. Boost Clock

Up to 5.0GHz

Base Clock

4.2GHz

L1 Cache

512KB

L2 Cache

8MB

L3 Cache

96MB

Default TDP

120W

Processor Technology for CPU Cores

TSMC 5nm FinFET

CPU Socket

AM5

Thermal Solution (PIB)

Not included

Recommended Cooler

Liquid cooler recommended for optimal performance

Max. Operating Temperature (Tjmax)

89°C

Windows 11 - 64-Bit Edition

Windows 10 - 64-Bit Edition

RHEL x86 64-Bit

Ubuntu x86 64-Bit

Connectivity

PCI Express Version

PCIe 5.0

System Memory Type

DDR5

Memory Channels

2

Max Memory Speed

2x1R

DDR5-5200

2x2R

DDR5-5200

4x1R

DDR5-3600

4x2R

DDR5-3600

Graphics Capabilities

Graphics Model

AMD Radeon Graphics

Graphics Core Count

2

Graphics Frequency

2200 MHz

Product IDs

Product ID Boxed

100-100000910WOF

Product ID Tray

100-000000910

Key Features

Supported Technologies

AMD EXPO Technology

AMD Ryzen Technologies
