Cisco Business 145AC 802.11ac 2x2 Wave 2 Access Point 4 GbE Ports One PoE - Wall Plate, Limited Lifetime Protection (CBW145AC-E)

Available transmit power settings

2.4 GHz
Up to 20 dBm

5 GHz
Up to 20 dBm

Note: The maximum power setting will vary by channel and according to individual country regulations. Refer to the product documentation for specific details.

Integrated antennas

• 2.4 GHz, gain 2 dBi

• 5 GHz, gain 3 dBi

Interface

• 1x Gigabit Ethernet uplink (10/100/1000BASE-T autosensing), PoE

• 3x Gigabit Ethernet local ports (10/100/1000BASE-T), including one PoE out port:

  • PoE out provides 802.3af (Class 0) when access point is powered by 802.3at, or no output when powered by 802.3af

• One passive pass-through port, RJ-45 (back to bottom)

Indicators

Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors

Dimensions (W x L x H)

Access point (without mounting bracket): 3.5 x 5.5 x 1.25 in. (89 x 140 x 31.5 mm)

Weight

Access point without mounting bracket or any other accessories: 10 oz (280 g)

Environmental

• Operating

  • Temperature: 32° to 104°F (0° to 50°C)

  • Humidity: 10% to 90% (noncondensing)

  • Maximum altitude: 9843 ft (3000 m) at 40°C

• Nonoperating (storage and transportation)

  • Temperature: –22° to 158°F (-30° to 70°C)

  • Humidity: 10% to 90% (noncondensing)

  • Maximum altitude: 15,000 ft (4500 m) at 25°C

System

• 1 GB DRAM

• 256 MB flash

• 710-MHz quad core processor

Powering options

• 802.3af/at Ethernet switch; a Cisco Business switch with PoE is recommended

• Optional Cisco Business PoE injector

Power draw

8.5W (maximum, without PoE)

Physical security

• Torx security screw, included with the access point

• Kensington lock slot to lock device to mounting bracket

Mounting

Bracket is included with the access point

Compliance

• Safety:

  • UL 60950-1

  • CAN/CSA-C22.2 No. 60950-1

  • UL 2043

  • IEC 60950-1

  • EN 60950-1

• Radio approvals:

  • FCC Part 15.247, 15.407

  • RSS-247 (Canada)

  • EN 300.328, EN 301.893 (Europe)

  • ARIB-STD 66 (Japan)

  • ARIB-STD T71 (Japan)

  • EMI and susceptibility (Class B)

  • FCC Part 15.107 and 15.109

  • ICES-003 (Canada)

  • VCCI (Japan)

  • EN 301.489-1 and -17 (Europe)

  • EN 50385

• IEEE standards:

  • IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d

  • IEEE 802.11ac

• Security:

  • 802.11i, WPA2, WAP3, WPA

  • 802.1X

  • AES

• Extensible Authentication Protocol (EAP) types:

  • EAP-Transport Layer Security (TLS)

  • EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)

  • Protected EAP (PEAP) v0 or EAP-MSCHAPv2

  • EAP-Flexible Authentication via Secure Tunneling (FAST)

  • PEAP v1 or EAP-Generic Token Card (GTC)

  • EAP-Subscriber Identity Module (SIM)

• Multimedia:

  • Wi-Fi Multimedia (WMM)

• Other:

  • FCC Bulletin OET-65C

  • RSS-102

Warranty

Cisco Business limited lifetime hardware warranty
Free software updates, no service contract required
