| السلسلة |
PRIME |
| الموديل |
H610M-F D4 |
| الشريحة |
Intel H610 |
| المقبس |
Intel LGA1700 |
| نوع الذاكرة |
DDR4 |
| دعم الذاكرة |
2 x DIMM, Max. 64GB, DDR4 2133-3200 MHz, Non-ECC Un-buffered Memory, Dual Channel, Supports Intel XMP |
| منافذ التوسعة |
1 x PCIe 4.0 x16 slot (CPU); 1 x PCIe 3.0 x1 slot via chipset |
| التخزين |
1 x M.2 slot (Key M, PCIe 3.0 x4, 2242/2260/2280); 4 x SATA 6Gb/s ports |
| كرت الشبكة |
1 x Realtek 1Gb Ethernet |
| الصوت |
Realtek 7.1 Surround Sound High Definition Audio CODEC, up to 24-Bit/192kHz, Jack-detection, Multi-streaming, Audio Shielding, premium audio capacitors |
| منافذ USB |
Rear (6 total): 2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A. Front (4 total): 1 x USB 3.2 Gen 1 header (2 ports), 1 x USB 2.0 header (2 ports) |
| لوحة التوصيلات الخلفية |
2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A, 1 x D-Sub port, 1 x Realtek 1Gb LAN port, 3 x Audio jacks, 1 x PS/2 keyboard port, 1 x PS/2 mouse port |
| التوصيلات الداخلية |
1 x 4-pin CPU Fan, 1 x 4-pin Chassis Fan header, 1 x 24-pin Main Power, 1 x 4-pin +12V, 1 x M.2 slot, 4 x SATA 6Gb/s ports, 1 x USB 3.2 Gen 1 header, 1 x USB 2.0 header, Clear CMOS header, Front Panel Audio header (AAFP), Speaker header, System Panel header |
| البايوس |
128 Mb Flash ROM, UEFI AMI BIOS |
| مميزات خاصة |
ASUS 5X Protection III (DIGI+ VRM, LANGuard, Overvoltage Protection, SafeSlot Core, Stainless-Steel Back I/O), Q-Design (Q-DIMM, Q-Slot), Aluminum heatsink design |
| أنظمة التشغيل المدعومة |
Windows 11 64-bit, Windows 10 64-bit |
| الملحقات |
2 x SATA 6Gb/s cables, 1 x I/O Shield, 1 x M.2 anchor, 1 x User guide |
| الأبعاد |
mATX Form Factor, 22.6 x 19.3 cm (8.9 x 7.6 inch) |
