| العلامة التجارية |
ASUS |
| السلسلة |
ROG Strix |
| الموديل |
B860-A Gaming WiFi |
| الشريحة |
Intel B860 |
| المقبس |
Intel LGA1851 |
| نوع الذاكرة |
DDR5 |
| دعم الذاكرة |
4 x DIMM, Max. 256GB, DDR5 up to 8600+ MT/s (OC), Non-ECC Un-buffered, Clocked Unbuffered DIMM (CUDIMM) support, Dual Channel, Intel XMP, ASUS Enhanced Memory Profile III (AEMP III) |
| منافذ التوسعة |
1 x PCIe 5.0 x16 slot (CPU); 1 x PCIe 4.0 x16 slot via chipset (x4 mode) |
| التخزين |
4 x M.2 slots (M.2_1 PCIe 5.0 x4, M.2_2/M.2_3/M.2_4 PCIe 4.0 x4, M.2_4 shares bandwidth with PCIEX16 G4); 4 x SATA 6Gb/s ports; Intel Rapid Storage Technology supports SATA RAID 0/1/5/10 |
| كرت الشبكة |
1 x Intel 2.5Gb Ethernet with ASUS LANGuard, plus Wi-Fi 7 (802.11be) 2x2 up to 2.9Gbps, Bluetooth 5.4 |
| الصوت |
Realtek ALC1220P 7.1 Surround Sound HD Audio CODEC, up to 32-Bit/192kHz playback, 120dB SNR playback / 113dB SNR recording, SupremeFX Shielding, Savitech SV3H712 AMP, rear optical S/PDIF out |
| منافذ USB |
Rear (10 total): 1 x USB4 20Gbps Type-C, 3 x USB 10Gbps (2x Type-A + 1x Type-C), 2 x USB 5Gbps Type-A, 4 x USB 2.0 Type-A. Front (5 total): 1 x USB 10Gbps Type-C connector, 1 x USB 5Gbps header (2 ports), 1 x USB 2.0 header (2 ports) |
| لوحة التوصيلات الخلفية |
1 x USB4 20Gbps Type-C, 3 x USB 10Gbps, 2 x USB 5Gbps, 4 x USB 2.0, 1 x DisplayPort, 1 x HDMI, 1 x Wi-Fi module, 1 x Intel 2.5Gb LAN port, 2 x Audio jacks, 1 x Optical S/PDIF out, 1 x BIOS FlashBack button, 1 x Clear CMOS button |
| التوصيلات الداخلية |
1 x 4-pin CPU Fan, 1 x 4-pin CPU OPT Fan, 1 x 4-pin AIO Pump, 4 x 4-pin Chassis Fan headers, 1 x 24-pin Main Power, 2 x 8-pin +12V CPU, 4 x M.2 slots, 4 x SATA 6Gb/s, 1 x USB 10Gbps Type-C connector, 1 x USB 5Gbps header, 1 x USB 2.0 header, 3 x Addressable Gen2 headers, Front Panel Audio header (F_AUDIO), Front System Panel header, Thermal Sensor header, Thunderbolt (USB4) header |
| البايوس |
256 Mb Flash ROM, UEFI AMI BIOS |
| مميزات خاصة |
ROG SupremeFX audio, BIOS FlashBack, Clear CMOS button, Aura Sync, Q-Design suite |
| أنظمة التشغيل المدعومة |
Windows 11 (22H2 and later) |
| الأبعاد |
ATX Form Factor, 30.5 x 24.4 cm (12 x 9.6 inch) |
