XPG CORER REACTOR II 1000W PCIE 5 & ATX 3.0 Power Supply - Full Modular - 80+ GOLD Certified - 100% Japanese 105°C Capacitors

• Description

General:

• 80 Plus Rating: GOLD

• ATX Version: ATX 3.0 & ATX 3.1

Protections:

• OCP (Over Current Protection)

• OVP (Over Voltage Protection)

• OPP (Over Power Protection)

• OTP (Over Temperature Protection)

• UVP (Under Voltage Protection)

• SCP (Short Circuit Protection)

• NLO (No Load Operation)

• SIP (Surge and Inrush Protection)

Certifications:

• CE

• CB

• FCC (IC)

• TUV

• cTUVus

• TUV S-Mark

• NOM

• BSMI

• UKCA

• EAC

• CCC

• RCM

Power Factor Correction:

• PFC > 0.99

Input Specifications:

• Voltage: 100-240V

• Current: 12A

• Frequency: 47Hz-63Hz

DC Output Voltages:

• +5V

• +3.3V

• +12V

• -12V

• +5Vsb

Total Output:

• +5V/+3.3V : 22A

• +12V : 70.8A

• -12V : 0.3A

• +5Vsb : 3A

Power Excursion:

• 1997W (up to 235% of the PSU's rated power for 100μs)

Operating Temperature:

• 50°C

Fan:

• Size: 120mm FDB (Fluid Dynamic Bearing) Fan

• Bearing: FDB (Fluid Dynamic Bearing)

• Speed: 2400 RPM

MTBF:

• 100K hours at full load

Connectors:

• ATX 24 Pin: 1

• EPS 8 Pin: 2

• PCI-E 6+2 Pin: 6

• Molex 4 Pin: 4

• 12VHPWR (12 + 4) Connector (600W): 1

• SATA Connector: 8

Unleash the full potential of your computer system with the XPG Core Reactor II 1000W Power Supply. Crafted to deliver unparalleled reliability and efficiency, this powerhouse is perfect for gamers and PC builders seeking top-notch performance. Featuring premium components and a sophisticated design, the Core Reactor II not only excels in functionality but also adds a sleek aesthetic to your setup. Ideal for high-demand applications, this power supply ensures your system runs smoothly and efficiently, making it a must-have for any serious PC enthusiast.
