XPG PROBE 700W +80 BRONZE POWER SUPPLY
XPG PROBE 700W +80 BRONZE POWER SUPPLY
E£2800.00
Dimensions (L x W x H)
140 x 150 x 86mm
80 Plus Rating
BRONZE
ATX Version
ATX 2.52
Protections
OVP / OPP / SCP / UVP / OTP / SIP
Certification
CB, CE, FCC, TUV, cTUVus, BSMI, CCC, NOM, FCC IC, UKCA,EAC, RCM
PFC
> 0.99 @ Typical load
Input Voltage
100-240V, 47~63Hz
Input Current
9A - 10A
Input Frequency
47 - 63Hz
DC Output Voltage
+5V | +3.3V | +12V | -12V | +5Vsb
Total Output
700W: +5V: 17A, +3.3V:19A, +12V:54A, -12V:0.3A, +5Vsb:2.5A 600W: +5V: 17A, +3.3V:19A, +12V:46A, -12V:0.3A, +5Vsb:2.5A
Power Excursion
Total:700W +5V/+3.3V:110W, +12V:648W, -12V:3.6W, +5Vsb:12.5W Total:600W +5V/+3.3V:110W, +12V:552W, -12V:3.6W, +5Vsb:12.5W
Operating Temperature
0~40°C
Fan Size
120mm
Fan Bearing
Sleeve Bearing Fan
Fan Speed
2400 ± 10% RPM
MTBF
>100,000 hours @ 25°C
ATX 24 Pin Connector
1
EPS 8 (4+4) Pin Connector
2
Molex 4 Pin Connector
2
SATA Connector
5
Weight
700W:1526.6g, 600W:1480.1g
Warranty
3 years
Discover the XPG PROBE Power Supply Unit, designed to deliver exceptional performance and reliability for both gaming and workstations. Boasting a state-of-the-art quiet cooling fan, it ensures your system runs smoothly and silently, even during intense gaming or heavy workloads. Installing this power supply unit is a breeze, making it an ideal choice for both novice and seasoned users alike. Additionally, its compact design and sleek finish seamlessly blend with any PC build. Elevate your computing experience with the XPG PROBE, where power meets precision.
