| العلامة التجارية |
ASUS |
| السلسلة |
PRIME |
| الموديل |
A620M-K |
| الشريحة |
AMD A620 |
| المقبس |
AMD AM5 |
| نوع الذاكرة |
DDR5 |
| دعم الذاكرة |
2 x DIMM, Max. 96GB, DDR5 4800-7200+ MHz (OC), Non-ECC Un-buffered Memory, Dual Channel Memory Architecture, Supports AMD EXPO |
| منافذ التوسعة |
1 x PCIe 4.0 x16 slot (CPU, x16 mode, or x8/x4 mode for Ryzen 8000); 1 x PCIe 3.0 x1 slot via chipset |
| التخزين |
1 x M.2 slot (Key M, PCIe 4.0 x4, 2242/2260/2280); 4 x SATA 6Gb/s ports; AMD RAIDXpert2 supports PCIe RAID 0/1/10 and SATA RAID 0/1/10 |
| كرت الشبكة |
1 x Realtek 1Gb Ethernet |
| الصوت |
Realtek 7.1 Surround Sound High Definition Audio CODEC, up to 24-Bit/192kHz, Jack-detection, Multi-streaming, Audio Shielding, premium audio capacitors |
| منافذ USB |
Rear (6 total): 4 x USB 3.2 Gen 1 Type-A, 2 x USB 2.0 Type-A. Front (6 total): 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports) |
| لوحة التوصيلات الخلفية |
4 x USB 3.2 Gen 1 Type-A, 2 x USB 2.0 Type-A, 1 x VGA port, 1 x HDMI port, 1 x Realtek 1Gb LAN port, 3 x Audio jacks, 1 x PS/2 combo port |
| التوصيلات الداخلية |
1 x 4-pin CPU Fan, 1 x 4-pin Chassis Fan header, 1 x 24-pin Main Power, 1 x 8-pin +12V, 1 x M.2 slot, 4 x SATA 6Gb/s ports, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers, 2 x Addressable Gen 2 headers, Aura RGB header, Clear CMOS header, COM Port header, Front Panel Audio header (AAFP), S/PDIF Out header, Speaker header, SPI TPM header, System Panel header |
| البايوس |
256 Mb Flash ROM, UEFI AMI BIOS |
| مميزات خاصة |
ASUS 5X Protection III (DIGI+ VRM, LANGuard, Overvoltage Protection, SafeSlot Core, Stainless-Steel Back I/O), Q-Design (Q-DIMM, Q-LED Core, Q-Slot), Aluminum heatsink design, Aura Sync RGB header |
| أنظمة التشغيل المدعومة |
Windows 11, Windows 10 64-bit |
| الملحقات |
2 x SATA 6Gb/s cables, 1 x I/O Shield, 1 x Screw package for M.2 SSD, 1 x User guide |
| الأبعاد |
micro-ATX Form Factor, 22.6 x 22.1 cm (8.9 x 8.7 inch) |
