| العلامة التجارية |
ASUS |
| السلسلة |
PRIME |
| الموديل |
B650M-A II |
| الشريحة |
AMD B650 |
| المقبس |
AMD AM5 |
| نوع الذاكرة |
DDR5 |
| دعم الذاكرة |
4 x DIMM, Max. 192GB, DDR5 4800-7600+ MHz (OC), Dual Channel Memory Architecture, Supports AMD EXPO, OptiMem II, ECC and Non-ECC Un-buffered Memory |
| منافذ التوسعة |
1 x PCIe 4.0 x16 slot (CPU, Ryzen 9000/7000 series x16 mode, Ryzen 8000 series x8/x4 mode); 2 x PCIe 4.0 x16 slots via chipset (x1 mode) |
| التخزين |
2 x M.2 slots (Key M, 2242/2260/2280, PCIe 5.0/4.0 x4 depending on CPU); 4 x SATA 6Gb/s ports; AMD RAIDXpert2 supports PCIe RAID 0/1/10 and SATA RAID 0/1/10 |
| كرت الشبكة |
1 x Realtek 2.5Gb Ethernet |
| الصوت |
Realtek 7.1 Surround Sound High Definition Audio CODEC, up to 24-Bit/192kHz, Jack-detection, Multi-streaming, Front Panel Jack-retasking, Audio Shielding, Premium audio capacitors |
| منافذ USB |
Rear (8 total): 2 x USB 3.2 Gen 2 Type-A, 2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A. Front (7 total): 1 x USB 3.2 Gen 1 Type-C connector, 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports) |
| لوحة التوصيلات الخلفية |
2 x USB 3.2 Gen 2 Type-A, 2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A, 1 x DisplayPort, 1 x VGA, 1 x HDMI, 1 x Realtek 2.5Gb LAN port, 3 x Audio jacks, 1 x BIOS FlashBack button, 1 x PS/2 combo port |
| التوصيلات الداخلية |
1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 3 x 4-pin Chassis Fan headers, 1 x 24-pin Main Power connector, 1 x 8-pin +12V Power connector, 2 x M.2 slots, 4 x SATA 6Gb/s ports, 1 x USB 3.2 Gen 1 Type-C connector, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers, 3 x Addressable Gen 2 headers, 1 x Aura RGB header, Clear CMOS header, COM Port header, Front Panel Audio header (AAFP), S/PDIF Out header, Speaker header, SPI TPM header, System Panel header |
| البايوس |
256 Mb Flash ROM, UEFI AMI BIOS |
| مميزات خاصة |
ASUS 5X Protection III (DIGI+ VRM, LANGuard, Overvoltage Protection, Safeslot Core+, Stainless-Steel Back I/O), ASUS Q-Design (Q-DIMM, Q-LED Core, Q-Slot), VRM heatsink design, BIOS FlashBack button and LED, Aura Sync RGB header |
| أنظمة التشغيل المدعومة |
Windows 11, Windows 10 64-bit |
| الملحقات |
2 x SATA 6Gb/s cables, 1 x I/O Shield, 1 x Screw Package for M.2 SSD, 1 x User guide |
| الأبعاد |
mATX Form Factor, 24.4 x 24.4 cm (9.6 x 9.6 inch) |
