| العلامة التجارية |
ASUS |
| السلسلة |
ROG Strix |
| الموديل |
Z890-E Gaming WiFi |
| الشريحة |
Intel Z890 |
| المقبس |
Intel LGA1851 |
| نوع الذاكرة |
DDR5 |
| دعم الذاكرة |
4 x DIMM, Max. 256GB, DDR5 up to 9200+ MT/s (OC), Non-ECC, Clocked Unbuffered DIMM (CUDIMM) support, Dual Channel, Intel XMP, DIMM Flex, NitroPath DRAM Technology, ASUS Enhanced Memory Profile III (AEMP III) |
| منافذ التوسعة |
1 x PCIe 5.0 x16 slot (CPU, supports x16 or x8/x4/x4 modes); 1 x PCIe 4.0 x16 slot via chipset (x4 mode) |
| التخزين |
7 x M.2 slots + 4 x SATA 6Gb/s ports. M.2_1 PCIe 5.0 x4 (2242/2260/2280/22110), M.2_2 PCIe 4.0 x4, M.2_3 & M.2_4 PCIe 5.0 x4, M.2_5 & M.2_6 PCIe 4.0 x4, M.2_7 PCIe 4.0 x4 & SATA. Intel Rapid Storage Technology supports PCIe/SATA RAID 0/1/5/10 |
| كرت الشبكة |
1 x Realtek 5Gb Ethernet with ASUS LANGuard, plus Wi-Fi 7 and Thunderbolt 4 |
| الصوت |
ROG SupremeFX 7.1 Surround Sound HD Audio CODEC ALC4080, Savitech SV3H712 AMP, up to 32-Bit/384kHz playback, 120dB SNR playback / 110dB SNR recording, gold-plated audio jacks, rear optical S/PDIF out, Audio Shielding |
| منافذ USB |
Rear (14 total): 2 x Thunderbolt 4 Type-C, 9 x USB 10Gbps (7x Type-A + 2x Type-C, one with 30W PD), 3 x USB 5Gbps Type-A. Front (11 total): 1 x USB 20Gbps Type-C, 2 x USB 5Gbps headers (4 ports), 3 x USB 2.0 headers (6 ports) |
| لوحة التوصيلات الخلفية |
2 x Thunderbolt 4 Type-C, 9 x USB 10Gbps, 3 x USB 5Gbps, 1 x DisplayPort, 1 x HDMI, 1 x Wi-Fi Module, 1 x Realtek 5Gb LAN, 2 x gold-plated audio jacks, 1 x Optical S/PDIF out, 1 x BIOS FlashBack button, 1 x Clear CMOS button |
| التوصيلات الداخلية |
1 x 4-pin CPU Fan, 1 x 4-pin CPU OPT Fan, 1 x 4-pin AIO Pump, 5 x 4-pin Chassis Fan headers, 1 x 24-pin Main Power, 2 x 8-pin +12V CPU, 7 x M.2 slots, 4 x SATA 6Gb/s, 1 x USB 20Gbps Type-C, 2 x USB 5Gbps headers, 3 x USB 2.0 headers, 3 x Addressable Gen2 headers, Chassis Intrusion header, CPU Over Voltage jumper, FlexKey button, Front Panel Audio header, Start button, System Panel header, PCIe mode switch, Thermal Sensor header, Thunderbolt (USB4) header |
| البايوس |
256 Mb Flash ROM, UEFI AMI BIOS |
| مميزات خاصة |
Dual Thunderbolt 4, Wi-Fi 7, 18+1+2+2 power stages, ROG SupremeFX audio, Aura Sync, Q-Design suite, BIOS FlashBack, Clear CMOS button |
| أنظمة التشغيل المدعومة |
Windows 11 (22H2 and later) |
| الأبعاد |
ATX Form Factor, 30.5 x 24.4 cm (12 x 9.6 inch) |
