| العلامة التجارية |
ASUS |
| السلسلة |
TUF Gaming |
| الموديل |
B650-E WIFI |
| الشريحة |
AMD B650 |
| المقبس |
AMD AM5 |
| نوع الذاكرة |
DDR5 |
| دعم الذاكرة |
4 x DIMM, Max. 192GB, DDR5 4800-8000+ MHz (OC), Dual Channel Memory Architecture, Supports AMD EXPO, OptiMem II, ECC and Non-ECC Un-buffered Memory |
| منافذ التوسعة |
1 x PCIe 4.0/3.0 x16 slot (CPU, or x8/x4 mode for Ryzen 8000); 1 x PCIe 4.0/3.0 x16 slot via chipset (x1 mode); 1 x PCIe 4.0/3.0 x1 slot |
| التخزين |
3 x M.2 slots (M.2_1 PCIe 5.0 x4 on Ryzen 9000/7000, M.2_2 PCIe 4.0 x4, M.2_3 PCIe 4.0 x4 via chipset); 4 x SATA 6Gb/s ports; AMD RAIDXpert2 supports PCIe RAID 0/1/10 and SATA RAID 0/1/10 |
| كرت الشبكة |
1 x Realtek 2.5Gb Ethernet with TUF LANGuard, plus Wi-Fi 6E (802.11ax) 2x2, Bluetooth 5.3 |
| الصوت |
Realtek 7.1 Surround Sound High Definition Audio CODEC, up to 24-Bit/192kHz, Jack-detection, Multi-streaming, Audio Shielding, premium audio capacitors, audio cover |
| منافذ USB |
Rear (8 total): 2 x USB 10Gbps (1x Type-A + 1x Type-C), 3 x USB 5Gbps Type-A, 3 x USB 2.0 Type-A. Front (7 total): 1 x USB 20Gbps Type-C connector, 1 x USB 5Gbps header (2 ports), 2 x USB 2.0 headers (4 ports) |
| لوحة التوصيلات الخلفية |
2 x USB 10Gbps (1x Type-A + 1x Type-C), 3 x USB 5Gbps Type-A, 3 x USB 2.0 Type-A, 1 x DisplayPort, 1 x HDMI, 1 x Wi-Fi Module, 1 x Realtek 2.5Gb LAN port, 5 x Audio jacks, 1 x BIOS FlashBack button |
| التوصيلات الداخلية |
1 x 4-pin CPU Fan, 1 x 4-pin CPU OPT Fan, 1 x 4-pin AIO Pump, 4 x 4-pin Chassis Fan headers, 1 x 24-pin Main Power, 1 x 8-pin +12V, 1 x 4-pin +12V, 3 x M.2 slots, 4 x SATA 6Gb/s ports, 1 x USB 20Gbps Type-C connector, 1 x USB 5Gbps header, 2 x USB 2.0 headers, 3 x Addressable Gen 2 headers, Aura RGB header, Clear CMOS header, COM Port header, Front Panel Audio header (AAFP), System Panel header with chassis intrude |
| البايوس |
256 Mb Flash ROM, UEFI AMI BIOS |
| مميزات خاصة |
ASUS TUF Protection (DIGI+ VRM with DrMOS, Enhanced DRAM Overcurrent Protection, ESD Guards, TUF LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O), Q-Design (M.2 Q-Latch, Q-DIMM, Q-LED, Q-Slot), M.2 & VRM heatsinks, BIOS FlashBack, ProCool, pre-mounted I/O shield, SafeDIMM, Aura Sync RGB header |
| أنظمة التشغيل المدعومة |
Windows 11, Windows 10 64-bit |
| الأبعاد |
ATX Form Factor, 30.5 x 24.4 cm (12 x 9.6 inch) |
